4.6 Measuring Ranges
────────────────────────────────────────────────────
NOTE
Display:
Display:
Dynamic range overflow
This is displayed if, while a waveform is being input (A/D conversion), the
input goes outside of the range defined by the minimum and maximum values.
If this occurs, change the range settings to accommodate the input. However,
detected minimum/maximum values are displayed and held for all measured
values (even if they exceed 130%f.s. of the range in question) aside from
values outside of the dynamic range.
Over range
The measured values that are displayed for each voltage, current and power
range can range from 0.4%f.s. to 130%f.s. The "Over range" message is
displayed when the measurement value of the input signal exceeds 130%f.s.
In this event, change the range setting so that it can accommodate the input.
