4.6 Measuring Ranges
────────────────────────────────────────────────────
*Auto-range threshold valu
e
Display rang
e
Valid measurement
range
Auto-range operation
↑Increases to the next higher range
↓Decreases to the next lower rang
e
Rang
e
Input voltag
e
Voltage Ranges
Display range
*Auto-range threshold valu
e
Valid measurement
range
Auto-range operation
↑Increases to the next
higher range
↓Decreases to the next lowe
r
range
Rang
e
Input curren
t
Current Ranges
4
.6 Measuring Ranges
The voltage and current ranges current ranges are set by using special voltage
and range keys. The setting can be set either automatically (auto-range
function) or manually. The display ranges and the valid measurement ranges
(the range over which accuracy is guaranteed) for the measurement ranges are
as shown below.
