8.4 Saving the Settings to Floppy Disk
────────────────────────────────────────────────────
NOTE
8
.4 Saving the Settings to Floppy Disk
Pressing the SAVE key while either page 1 or page 2 of the "Function Settings"
screen is displayed causes all of the current power meter settings to be saved
to floppy disk.
In addition to the items that were set in "Setting" mode, the special settings
that were set for each measurement mode are also saved.
This function can also be executed in the same manner from the setting
screens for each measurement mode.
1. Press the SAVE key.
2. The setting conditions are saved to floppy disk in a file named "SETXXX."
Note that the saved setting conditions are loaded in "FD" mode. (Refer to
section 14.6.1, "Loading Previously Saved Setting Data.")
・A file named "SETXXX" is generated automatically and the setting conditions
are saved in that file.
"XXX" represents a number from "000" to "999"; the program uses the smallest
number that is still available.
・Changing file names as necessary makes it easier to identify the contents
saved in each file. File names can be changed in "FD" mode.
・In order to save measurement data to floppy disk, the optional 9595 FDD
UNIT must be connected to the power meter.
