Hioki 3166 - Chapter 6 Integrated Measurement; Capabilities in Integrated Measurement Mode

63
────────────────────────────────────────────────────
6.1 Capabilities in Integrated Measurement Mode
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
Chapter
6
Integrated Measureme
nt
6
.1 Capabilities in Integrated Measurement Mode
In "Integrated Measurement" mode, in addition to being able to measure
instantaneous values for voltage, current, power, etc., and to measure the
minimum and maximum instantaneous values, integrated power
measurements are also possible.
When taking demand measurements, select "Demand" mode.
This chapter explains the necessary settings for integrated measurement, how
to display various measured values, and how to save data to floppy disk or
print it on the printer.
Reference If "Integrated Measurement" mode is used, the measurements taken in
"Normal Measurement" mode are included as well. It is also possible to
take integrated measurements, adding the measurements to the
integrated values from previous measurements.
The following measurement display functions and data processing functions
can be used in integrated measurement mode.
●Display (Refer to section 18.3, "Measurement Items and Calculations"
for details on the items that are displayed.)
(1) Instantaneous value display
(2) Instantaneous value minimum/maximum display (including display of the time
at which the minimum/maximum value was generated)
(3) Integrated value display
1. Integrated value display screen (page 1/2) (displays power integration
consumption and average value)
2. Integrated value display screen (page 2/2) (displays details about power
integration, such as power consumption/regeneration)
