Hioki 3166 - Frequency of the Line Being Measured; Display Averaging Times

127
────────────────────────────────────────────────────
8.2 Settings for Each Item
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
8
.2.4 Frequency of the Line Being Measured
NOTE
8
.2.5 Display Averaging Times
This item sets the frequency of the line being measured. When using a fixed
clock, the sampling frequency is based on this frequency, so be certain to
adjust this setting to the frequency of the line being measured before the start
of measurement.
・Even if the sampling method is PLL sync, set the frequency of the line being
measured.
・Correct measurement is impossible if this setting does not agree with the
frequency of the line being measured. In addition, if a fixed clock is being
used and the frequency of the line being measured fluctuates, errors in the
measurements will result.
Options: 50/60/400 Hz
*50 Hz
Example Changing the setting for the frequency of the line being measured to "60
Hz"
Position the cursor at the "Frequency of the line being measured (MEASURE
LINE FREQUENCY)" item.
Pressing the 60 Hz function key.
"60 Hz" is set and is displayed in the "Frequency of the line being measured"
field.
This item sets the process count when the displayed value is a moving average
of the measured values.
This setting is useful, for example, if there is a great deal of fluctuation on the
line being measured.
Options: OFF/2/3/4/5/6/7/8/9/10 times
*OFF
Example Changing the averaging times to "8"
Position the cursor at "Display averaging times (DISPLAY AVERAGE
TIMES)" item.
Using the the ＋ and − function keys, set the digit to "8".
"8 times" is displayed and set in the "Display averaging times" field.
