128
────────────────────────────────────────────────────
8.2 Settings for Each Item
────────────────────────────────────────────────────
8
.2.6 PT
8
.2.7 CT
This item lets you set the PT ratio as desired.
The values that are displayed are multiplied by the PT ratio.
Setting range: 00001 to 10000
*00001
Example Setting the PT ratio to "30"
Position the cursor at the "PT" item.
Pressing the CHANGE key causes the "PT Input Window" to be displayed.
The cursor appears at the first digit.
Move the cursor left or right until it is positioned at the ten’s digit.
Move the cursor up or down until the digit is set to "3".
Press the − function key once to set the digit to "0".
"00030" is set and is displayed in the "PT ratio" field.
Once the SET function key is pressed, "00030" is set and is displayed in the
"PT ratio" field.
This item lets you set the CT ratio as desired.
The values that are displayed are multiplied by the CT ratio.
Setting range: 00000.01 to 10000.00
*00001.00
Example Setting the CT ratio to "60"
Position the cursor at the "CT" item.
Pressing the CHANGE key causes the "CT Input Window" to be displayed.
The cursor appears at the first digit.
Move the cursor left or right until it is positioned at the hundred’s digit.
Move the cursor up or down until the digit is set to "6".
Move the cursor left or right until it is positioned at the one’s digit.
Move the cursor up or down until the digit is set to "0".
Once the SET function key is pressed, "00060.00" is set and is displayed in the
"CT ratio" field.
