1.3 Names and Functions of Each Part
────────────────────────────────────────────────────
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
7
8
9
1
1
Print key (PRINT)
This key is used to manually print the measured values if there is a printer
connected to the interface connector.
Save key (SAVE)
This key is used to manually save measured values and setting conditions on
floppy disk if a floppy disk drive unit is connected to the 3166.
Measurement data reset key (DATA RESET)
This key is used to reset (clear) measurement data for integrated values and
maximum/minimum values.
Measurement start/stop key (START/STOP)
This key is used to start/stop integrated and demand measurement.
Cursor key
This key is used to select setting items displayed on the screen, and to change
those settings. Pressing on the up, down, left, and right arrow portions of the
cursor key（▲・▼・ ・ ）moves the cursor in the corresponding direction
on the screen.
* Keys 3 through 11 above are printed in reverse in this manual (white on black).
