294
────────────────────────────────────────────────────
18.1 Product Specifications
────────────────────────────────────────────────────
Withstand voltage (50/60Hz, 1
minute)
5.55 kVAC: Between voltage input terminal and case
3.25 kV: Between voltage input terminal and current input
terminal, output terminal, external interface terminal
2.3 kVAC: Between power supply and case
1.35 kVAC: Between power supply and current input terminal,
output terminal, external interface terminal
Insulation resistance
More than 100 MΩ at 500 VDC
Between voltage input terminal and current input terminal,
output terminal, external interface terminal, case
More than 50 MΩ at 500 VDC
Between power supply and current input terminal, output
terminal, external interface terminal, case
Display
4.7-inch LCD (320×240 dots) adjustable contrast, backlight
Battery backup life
More than 10 years (25℃ (77 F) reference value)
Rated supply voltage
100 VAC to 240 VAC, 50/60 Hz
Rated power
33 VA max
External dimensions
246 (W) × 86 (H) ×176 (D)mm
(9.69" (W) × 3.39" (H) × 6.93" (D)) (not including projections)
Mass
1.6 kg (56.44 oz) (including 9594 D/A OUTPUT)
Applicable standards
Safety: EN61010-1:1993+A2:1995
Voltage inputs: Pollution level 2, overvoltage category III
(expected transient overvoltage: 6000 V)
Power supply: Pollution level 2, overvoltage category II
(expected transient overvoltage: 2500 V)
EMC: EN61326-1:1997+A1:1998
EN61000-3-2:1995+A1:1998+A2:1998
EN61000-3-3:1995
Accessories
9438 VOLTAGE CORD × 1 (one each black, red, yellow, and
blue)
Voltage cord locks × 4
Stand × 1
Power cord × 1
Instruction Manual × 1
Guide × 1
Options
9291 CLAMP ON SENSOR (AC 500 A)
9298 CLAMP ON SENSOR (AC 100 A)
9290 CLAMP ON PROBE
9594 D/A OUTPUT (including 9441 CONNECTION CABLE)
9595 FDD UNIT
9556 HARMONIC ANALYSIS SOFTWARE
9619-01 HARMONICS DATA ANALYSIS UTILITY (for the 9556)
9383 CARING CASE
9440 CONNECTION CABLE (for remote control)
9441 CONNECTION CABLE (for D/A output)
9442 PRINTER
9443-01 AC ADAPTER (for Japan)
9443-02 AC ADAPTER (for Europe, except for Switzerland)
9443-03 AC ADAPTER (for the U.S.A.)
9444 CONNECTION CABLE (for printer)
1196 PRINT PAPER
