8.1.3 Function Specifications
■ Normal Measurement mode
Instantaneous value display
Displays voltage, current, average voltage, average current,
active power, reactive power, apparent voltage, power factor,
and frequency.
* Active power display includes consumption/regeneration and
reactive power; power factor display includes lag/lead phase
polarity display
* Average value displays are available only when measuring
three currents on a three-phase, three-wire line or when
measuring a three-phase, four-wire line.
Minimum/maximum value
display
Displays minimum/maximum values for voltage, current, active
power, reactive power, apparent power, power factor, and
current.
* Reactive power and power factor displays include
minimum/maximum values for each lagging/leading phase.
Time of generation display
Displays time of generation for each minimum and maximum
value.
Contents of related settings
Contents of setting mode, etc.
Print/save items
Items to be printed on the printer/saved to floppy disk are
specified in 9 blocks (9 blocks arising from all possible
combinations of voltage, current and power with instantaneous
values, maximum values, and minimum values)
File names
Up to eight alphanumeric characters (normal width) or four
kanji (double width)
D/A output items
Voltage, current, active power, reactive power, apparent power,
power factor and frequency
■ Integrated Measurement mode
Instantaneous value display
Same as instantaneous value display contents for Normal
Measurement mode.
Minimum/maximum value
display
Same as minimum/maximum display contents for Normal
Measurement mode.
Contents of related settings
Contents of setting mode, etc.
Integrated displays 1 and 2
(Refer to Table 3.)
When not using reactive power
method measurement
Integrated display 1: Active power integration, reactive power
integration, apparent power integration, and average value
within a time period when power is being consumed
Integrated display 2: Active power integration
consumption/regeneration/addition, apparent power integration
consumption/regeneration/addition, and reactive power
integration while power is being consumed
When using reactive power
method measurement
Integrated display 1: Active power integration, lagged reactive
power integration, apparent power integration, and average
value within a time period when power is being consumed
Integrated display 2: Active power integration
consumption/regeneration/addition, reactive power integration
lag/lead/total, and apparent power integration while power is
being consumed
