18.1 Product Specifications
────────────────────────────────────────────────────
Weekly report display
Demand measurement results for a one-week period (7 days)
following the demand measurement starting date and time
Maximum demand value generation time: Generation time of
the maximum demand value for a one-week period (7 days)
following the demand measurement starting date and time
Minimum/maximum value
display
Same as minimum/maximum display contents for Normal
Measurement mode (during weekly report period).
Monthly report display
Demand measurement results for a one-month period (until the
same date and time of the following month) following the
demand measurement starting date and time (Auto calendar
function)
Maximum demand value generation time: Generation time of
the maximum demand value for a one-month period following
the demand measurement starting date and time
Minimum/maximum value
display
Same as minimum/maximum display contents for Normal
Measurement mode (during monthly report period).
Contents of related settings
Contents of setting mode, etc.
Start time
YY.MM.DD, HH.MM (24-hour system)
Stop time
YY.MM.DD, HH.MM (24-hour system)
Demand period
5 minutes/10 minutes/15 minutes/30 minutes/60 minutes/2
hours/3 hours/4 hours/6 hours/8 hours/12 hours
Transformer capacity
0.001 to 1000.000 kVA (in 0.001 kVA steps)
Print/save items
Integrated Measurement mode items, integrated , demand
values, daily report values, weekly report values, and monthly
report values
FD auto output
On/off
* The FD auto output time interval is the same as the demand
period.
File names
Up to eight alphanumeric characters (normal width) or four
kanji (double width)
RS-232C auto output
On/off
D/A output items
Same items as in Normal Measurement mode, and active power
integration (consumption, regeneration, addition)
Integrated output rates
5 V/5 kWh,5 V/10 kWh,5 V/50 kWh,5 V/100 kWh,5 V/500 kWh,
and 5 V/1 MWh
■
Displays results of harmonic analysis.
For details on display of measurements, settings, etc., refer to the specifications for the 9556 Harmonic
Analysis Software.
