3.4 Part Names/F
unctions and Ext
ernal
Dimensions
A3-
18
ME0384-4A
Chapter 3 Gateway Unit
Specifications Sect
ion
T
erminal unit
Item
Specifications
External
dimensions
W 12.6 mm
×
H 1
15 mm
×
D 95 mm
M
ass
About 4
8g
Exter
nal view
See figure below
12.6
98.8
95
11
5
120
122
