1.1 Overview
A1-1
ME0384-4A
1.1 Overview
RCON is a host programmable controller (hereafter PLC) dedicated for operating a ROBO
Cylinder or commercial robots using a field network.
1 gateway unit set serves as the field network connection interface to which multiple driver units
can be freely configured for control of up to 16 axes
(Note 1)
.
There are 7 types of gateways, for CC-Link, CC-Link IE Field, DeviceNet, EtherCAT, EtherNet
/IP, PROFIBUS-DP and PROFINET IO.
Also, there are 5 types of driver units, for RCP Series, for High-Thrust RCP Series, for RCA
Series, for RCD Series and for 200V Servo-motor. The unit for ELECYLINDER connection is
also available for combination.
Note 1: When direct numerical control mode is used with field networks other than CC-Link or
CC-Link IE Field, up to 8 axes can be connected.
Driver unit x 9 (16-axis specification)+ 200V Power Supply Unit, with fan unit
To Next Page
