IAI Rcon - Overall Address Configuration Example

4.4 Address Configuration
B4-48
ME0384-4A
Chapter 4 Network Configuration
Startup Section
Overall address configuration example
Shows the overall address configuration for each 4-word mode axis (simple direct/positioner 1)
for 12 axes, each 8-word mode axis (direct numerical control) for 2 axes connected, or each
2-word mode axis (positioner 2/positioner 5) for 16 axes connected.
Note that CC-Link and DeviceNet are assigned with word addresses while PROFIBUS uses byte
addresses.
[For CC-Link]
The following page shows a CC-Link configuration example.
Fixed 8-word region is assigned to the bit register (RX/RY), while the region for each axis is
assigned to the word register (RWr/RWw).
