IAI Rcon User Manual

2.2 Configuration Unit List
A2-3
ME0384-4A
Specifications Section
Chapter 2 System Configuration and Specifications
2.2 Configuration Unit List
The units that configure the RCON system are listed below.
Product name Model
Gateway unit
(GWG: Safety category type)
CC-Link connection type RCON-GW(GWG)-CC
CC-Link IE Field connection type RCON-GW(GWG)-CIE
DeviceNet connection type RCON-GW(GWG)-DV
EtherCAT connection type RCON-GW(GWG)-EC
EtherNet/IP connection type RCON-GW(GWG)-EP
PROFIBUS-DP connection type RCON-GW(GWG)-PR
PROFINET IO connection type RCON-GW(GWG)-PRT
Driver unit
24V
Stepper motor 1-axis specification RCON-PC-1
Stepper motor 2-axis specification RCON-PC-2
High thrust stepper motor 1-axis specification RCON-PCF-1
AC servo motor 1-axis specification RCON-AC-1
AC servo motor 2-axis specification RCON-AC-2
DC brush-less motor 1-axis specification RCON-DC-1
DC brush-less motor 2-axis specification RCON-DC-2
200V
AC Servo-motor Single-axis Type RCON-SC-1
EC Connection Unit
ELECYLINDER 4-axis Type RCON-EC-4
200V Power Supply Unit
Power Supply for 200V AC Input RCON-PS2-3
Terminal Unit
Terminal Resistor for 24V
(enclosed in Gateway Unit)
RCON-GW-TR
Terminal Unit for 200V
Terminal Resistor for 200V
(enclosed in 200V power supply unit)
RCON-GW-TRS
SCON Extension Unit
SCON-CB Connection Unit RCON-EXT
Terminal Connector
(enclosed in SCON-CB terminal
resistor and SCON extension unit)
RCON-EXT-TR
Simple Absolute Unit
(1-axis specification)
For Pulse Motor RCON-ABU-P
For AC Servo-motor RCON-ABU-A
Fan unit
• One unit available to install for two units
of 24V driver unit (number of enclosed
unit to be indicated in gateway unit)
• One unit to be installed for one unit of
200V power supply unit (enclosed in
200V power supply unit)
RCON-FU
200V Driver Fan Unit
One unit to be installed for one unit of 200V
driver unit (enclosed in 200V driver unit)
RCON-FUH
