4.4 Part Names/Functions and External Dimensions
A4-21
ME0384-4A
Specifications Section
Chapter 4 24V Driver Unit EC Connection Unit
[EC Connection Unit]
Part names
RCON-EC
T RUN LED
forward end LED
(1st to 4th Axes)
backward end LED
(1st to 4th Axes)
SYS LED
Brake Release Switch
(1st to 4th Axes)
Jog switch
(1st to 4th Axes)
Drive source shutoff connector
Connector upper part
DIN tab
Left side Right side
Connector bottom part
Connector
Connector
Rear
Front
