IAI Rcon User Manual

4.4 Address Configuration
B4-61
ME0384-4A
Startup Section
Chapter 4 Network Configuration
Power supply unit (PSA-24) status signal
Eight words of input and output from the top address of the gateway unit are the fixed domains.
Six words in these domains should be assigned as the power supply unit status signal domains
and the condition of the IAI 24V DC power supply unit PSA-24 can be checked.
(1) Address configuration
Request command region and response command region comprise 6 words for each I/O.
Address is the address relative to the gateway head.
(1) For CC-Link and CC-Link IE Field
Bit
PLC output ⇒ gateway ⇒ each axis input Each axis output ⇒ gateway ⇒ PLC input
Bit
Address
b15 High byte b8
b7 Low byte b0
b15 High byte b8
b7 Low byte b0
Address
RY 2F~20
Not available
Power supply unit status signal 0
RX 2F~20
RY 3F~30
Not available
Power supply unit status signal 1
RX 3F~30
RY 4F~40
Not available
Power supply unit status signal 2
RX 4F~40
RY 5F~50
Not available
Power supply unit status signal 3
RX 5F~50
RY 6F~60
Not available
Power supply unit status signal 4
RX 6F~60
RY 7F~70
Not available
Not available
RX 7F~70
(2) For DeviceNet
PLC output ⇒ gateway ⇒ each axis input Each axis output ⇒ gateway ⇒ PLC input
Word
Address
b15 High byte b8
b7 Low byte b0
b15 High byte b8
b7 Low byte b0
+2 Not available Power supply unit status signal 0
+3 Not available Power supply unit status signal 1
+4 Not available Power supply unit status signal 2
+5
Not available
Power supply unit status signal 3
+6 Not available Power supply unit status signal 4
+7
Not available
Not available
