IAI Rcon - Position Travel

5.1 Operation Confirmation with PC Software
B5-13
ME0384-4A
Startup Section
Position travel
Moves the actuator to the registered position (target position).
(1) Click and select the position No.
column to be moved.
(2) Click in the "Position travel"
column.
To stop, click .
1
Selection
Home
Moves to
Position No.1
100mm
Position No.1
Click
Stop
Click
● Starts the movement to the selected position.
Step travel
Stop
