5.4 Part Names/Functions and External Dimensions
A5-23
ME0384-4A
Chapter 5 200V Driver Unit 200V Power Supply Unit
Connectors
A connector for use between units. Two identical connectors are used. The connectors have a
floating structure that absorbs connector misalignment due to housing mating or mounting
misalignment between connectors.
Fan unit
It is a fun to have forced air cooling on the power supply unit. It is the same as the fan unit
attached on the 24V driver unit. Use the unit by connecting to the fan connector on the 200V
Power Supply Unit unit side. One unit of the 200V Power Supply Unit uses one unit of the fan
unit.
The fan starts turning if the temperature inside of the power supply unit gets high, and stops
when the temperature drops.
Plug side connector
Receptacle connector
Fan unit
Fan unit (Model: RCON-FU)
