5.4 Part Names/Functions and External Dimensions
A5-14
ME0384-4A
Chapter 5 200V Driver Unit 200V Power Supply Unit
Fan Unit for 200V Driver Unit
It is a fan to have forced air cooling on the driver unit. Use by connecting to the fan connector on
the driver unit side. One unit of the 200V driver unit requires one unit of the Fan Unit for 200V
Driver Unit.
The fan rotates when the driver unit internal temperature rises and stops when the temperature
falls.
Fan Unit for 200V Driver Unit
Fan Unit for 200V Driver Unit
To Next Page
