4.4 Part Names/Functions and External Dimensions
A4-19
ME0384-4A
Specifications Section
Chapter 4 24V Driver Unit EC Connection Unit
External dimensions (24V Driever unit, Fun unit)
24V Driver unit (common for RCON-PC/PCF/AC/DC types)
Item Specifications
External dimensions W22.6 mm × H115 mm × D95 mm
Mass About 180g
External view See figure below
1
22.6
7
98.8
95
4
3.5
115
39.6
35.2
