1.3 General Specifications
A1-8
ME0384-4A
Chapter 1 RCON Overview
Specifications Section
1.3 General Specifications
RCON system general specifications are listed below.
Item Specifications
Power supply voltage
DC24V±10％
AC200-230V±10％
Power supply current
Differs with system configuration
(refer to "2.3 Specifications/Power supply capacity (page A2-
10)" for details)
Power Supply Frequency
50/60Hz (only for 200V system)
Current Amperage
Refer to "2.3 Specifications / Power supply capacity (Page A2-
10)"
In-rush Current Refer to "2.3 Specifications / Inrush current (Page A2-18)"
Instantaneous Power
Outage Durability
24V System : By 24V power source
200V System : Control power supply is by 24V power source
Described as follows for motor power supply
20ms (50Hz)
16.6ms (60Hz)
Electric Shock Protection
24V System : Class III
200V System : Class I
Leakage Current
3.0mA or less (only for 200V system)
Number of controlled axes 1~16 axes
(Note 1)
(driver unit can be freely combined)
Supported field networks
CC-Link, CC-Link IE Field, DeviceNet, EtherCAT, EtherNet/IP,
PROFIBUS-DP, PROFINET IO (slave station)
Configuration units
Gateway unit, driver unit, EC connection unit, 200V power
supply unit, simple absolute unit and SCON extension unit
(refer to "2.2 Configuration Unit List (Page A2-3)" for detail)
Emergency stop/Enable
operation
STOP Signal input on gateway unit applied to driver unit and
EC connection unit at the same time, connectors equipped to
cut off driving power source to each axis on each driver unit
and EC connection unit
Ambient operating
temperature
From 0 to 55degC, however from 0 to 40degC for simple
absolute unit and SCON (refer to "2.3 Specifications /
Operating Temperature Range (Page A2-20)" for detail)
Regulation/standard
CE Marking, UL Certification
(Coming to acquire for 200V driver unit, 200V power supply unit
and EC connection unit)
External dimensions Differ with system configuration
Connections between each
unit
Unit connection method
(refer to "Startup Section 2.1 Installation/Unit connection (page
B2-5)" for details)
Installation/mounting
method
DIN rail (35 mm) mounting
Note 1: Maximum number of connectable axes
