3.9 Gateway Parameter Configuration Tool
A3-162
ME0384-4A
Explanations of Monitoring Menu Features
[I/O data (register monitor)]
The data that the gateway received from the master and transmission data returned to the
master are displayed on this register monitor screen.
• Data read cycle : Select the update cycle of the display data between 100 and 500 ms
• Display switch : Select either binary or hexadecimal display
• SYNC Scroll :
When checked, the transmitted/received data will be scrolled at the same
time
To Next Page
