4.4 Part Names/Functions and External Dimensions
A4-16
ME0384-4A
Chapter 4 24V Driver Unit EC Connection Unit
Specifications Section
Fan connector
A connector to connect the fan unit. It connects to the fan board connector on the fan unit side.
Connectors
A connector for use between units. Two identical connectors are used. The connectors have a
floating structure that absorbs connector misalignment due to housing mating or mounting
misalignment between connectors.
Fan connector
Plug side connector Receptacle connector
