IAI Rcon - Actuator Wiring

2.2. Wiring
B2-12
ME0384-4A
Chapter 2 Mounting and Wiring
Startup Section
Actuator wiring
[Checking actuator and controller model numbers]
Before connecting the actuator, make sure that the combination with the controller is correct.
Connectable actuator models are listed on the model number sticker on the left side of the
controller.
Items to prepare
Controller/actuator/motor encoder cable
Model number shown in "Actuator" on the controller model number sticker
Driver unit front
Match
Model number shown in "MODEL" on the actuator model number sticker
Actuator side surface
