2.1 Installation
B2-6
ME0384-4A
Chapter 2 Mounting an
d Wiring
Startup Section
DIN rail mounting
Pull down the DIN tab v
isible from the lower pa
rt of the housi
ng rear (circled i
n a dashed line in
the figure below), m
ount on the DIN rail
, then push the DIN operat
ing part upward to loc
k it.
Front
Rear
DIN tab
390
392
Table of Contents
