5.1 Operation Confirmation with PC Software
B5-1
ME0384-4A
5.1 Operation Confirmation with PC Software
Described below, shows how to check operation in PC software (RCON-101*-*).
Items to prepare
RCON system / actuator / PC / communication cable / motor/encoder cable
Connect the PC software.
Caution
● Operate the actuator through the following procedure. Before starting operation, make
sure that there is no interfering object within the movable range of the actuator.
(1) Connect the RCM-101 supplied cable as shown below.
Caution
● When connecting the RCM-101 supplied cable to the gateway unit "SIO" port, insert
matching the two white arrows as shown in the red frame above. Failure to do so may
cause damage to the connector.
RCON System
SIO port
To Next Page
