3.5 Field Network General Specifications
A3-24
ME0384-4A
Chapter 3 Gateway Unit
Specifications Section
PROFIBUS-DP
Cable side connector name: 9-pin D sub connector (male)
* It is to be prepared by the customer.
Pin No. Signal name Description
1 NC Not connected
2 NC Not connected
3 B-Line Signal line B (RS-485)
4 RTS Transmission request
5 GND 0 V (isolated)
6 +5 V +5 V output (isolated)
7 NC Not connected
8 A-Line Signal line A (RS-485)
9 NC Not connected
Housing FG
Frame ground (control power connector 1-pin FG
connected internally)
LED display
Name
Panel
notation
Display
color
Status Description
STATUS 0 MS
Green
Light ON Initialization complete
Blinking
Initialization complete, diagnosis event
found
Orange Light ON Exception error
Green/orange Light OFF Uninitialized
STATUS 1 NS
Green
Light ON Online, data exchange
Blinking Online, clear status
Orange
Light ON Parameter error
Blinking Configuration information error
Green/orange Light OFF Offline
5
9
6
1
