IAI Rcon - Overall Address Configuration Example

3.7 Address Configuration
A3-32
ME0384-4A
Chapter 3 Gateway Unit
Specifications Section
Overall address configuration example
Here shows an example for the overall address configuration when four-word mode axes
(Simple Direct / Positioner 1) are connected for 12 axes, eight-word mode axes (Direct
Indication) for two axes are connected, and also the overall address configuration when two-
word mode axes (Positioner 2 / Positioner 5) for 12 axes and one unit of the EC connection unit
are connected.
Note that CC-Link and DeviceNet are assigned with word addresses while PROFIBUS uses
byte addresses.
[For CC-Link]
The following page shows a CC-Link configuration example.
Fixed 8-word region is assigned to the bit register (RX/RY), while the region for each axis is
assigned to the word register (RWr/RWw).
