3.3 Parameter Setting
B3-6
ME0384-4A
3.3 Parameter Setting
In the RCON system, the factory default setting of the parameter No. 83 "Absolute unit" is "0".
For an axis connected with the simple absolute unit and used in the simple absolute type,
change the parameter to "1" in the teaching tool.
[Absolute Unit (Parameter No.83)]
No. Name Unit Input range
Default initial value setting
83 Absolute Unit －
0: Not in use
1: In use
0
For stepper motor specification
Set 1 for simple absolute specification.
For the battery-less absolute specification, the factory default value is 1. Change the setting to 0
when using in incremental specification.
For 24V AC servo motor specification
Set 1 for simple absolute specification.
Battery-less absolute specification cannot be used in incremental specification.
For the PC software, the parameter changes automatically when connected to RCON.
24V AC servo motor specification and
stepper motor specification only
