3.2 Simple Absolute Unit Wiring
B3-3
ME0384-4A
Startup Section
Chapter 3 Absolute Reset
3.2 Simple Absolute Unit Wiring
When using a simple absolute unit, perform wiring as shown below.
1 simple absolute unit is required for each actuator.
Driver cable connector (CONT)
Actuator connection
Connector (MPG)
CB-ADPC-MPA005
(Supplied with Simple Absolute Unit)
RCON System
Simple Absolute Unit
Actuator
Driver unit
For the wiring of this section,
refer to the RCON connection
cable list
on the next page.
