3.1 Absolute Reset
B3-2
ME0384-4A
Note 1 The following 200V servo-motor actuators cannot be connected to the 200V driver units.
(1) Motor types other than those from 60W to 750W
(2) Encoder types other than battery-less absolute, incremental, spurious absolute or index absolute type
(3) For 3-Phase 200V ········· Combination that exceeds 2400W for total wattage of actuators connected to
200V driver unit
(4) For Single-Phase 200V ·· Combination that exceeds 1600W for total wattage of actuators connected to
200V driver unit
(5) Servo press type
(6) SCARA robot
(7) CT4 series
(8) ZR series
When connecting the actuators described in (1) to (4), use SCON extension unit and SCON-CB.
Also, DD/DDA and LSA-W21S are not applicable for the single-phase 200V.
Note 2 There is a built-in regenerative resistor of 60W equipped in 200V driver unit and 200V power supply unit.
The regenerative resistor is basically not necessary, but use this external regenerative resistor in case of
shortage in regenerative resistor.
To Next Page
