IAI Rcon User Manual

3.8 I/O Signals
A3-119
ME0384-4A
Specifications Section
Chapter 3 Gateway Unit
For details on th e gateway status signal, refer to "3.7 Address Configuration / Gateway control /
status signal (page A3-43)".
20ms (TYP)
Drive-source cutoff cancel
Drive-source cutoff status
Safety circuit status
Control power [Input]
(24 VDC)
Motor power [Input]
(24 VDC/AC200V)
Servo ON signal
(Note 3)
SON [Input]
Home return signal
HOME (STO/ST1) [Input]
Home return complete
HEND (LS0/LS1) [Output]
EC Connection Unit
Backward (Forward) End Turns
Green Light on
Actuator operation
Gateway status signal 1
LNK* [Output]
(Note 4)
Operation ready signal
SV [Output]
Driver unit
SYS lit green
Gateway status signal 0
RUN [Output]
(Note 1)
(Note 2)
Home position
(ELECYLINDER moves from the home
position to backward (forward) end)
