3.8 I/O Signals
A3-146
ME0384-4A
The basic time chart is as follows.
Caution
● The pressing operation speed is 20 mm/s.
Refer to an instruction manual of each ELECYLINDER or a catalog for detail.
● The workpiece remains pressed after the pressing is completed.
If the workpiece moves or pushes back, it may be pressed even further.
● Hitting a workpiece during the approaching operation will cause "Alarm Group A:
Overload Alarm".
PE signal ON
Pressing
Not ON
at failure to contact
