3.9 Gateway Paramet
er
Configuratio
n
T
ool
A3-
179
ME0384-4A
Specifications Sect
ion
Chapter 3 Gateway Unit
Delete the driv
er unit
(1)
On the "A
xis numb
er ass
ignment /
Unit conf
igurati
on confi
rmatio
n screen
", press
"
Deletin
g
unit".
(2) "Deleting unit
screen" opens.
Select the driver uni
ts to be deleted and pres
s "Complete".
5
281
283
