4.4 Part Names/Functions and External Dimensions
A4-14
ME0384-4A
Chapter 4 24V Driver Unit EC Connection Unit
RCON-DC Driver Unit
Pin No. Signal name Description
1 B+ Encoder phase B+ input
2 LS- Limit switch - side
3 U Motor drive line phase U
4 W Motor drive line phase W
5 V Motor drive line phase V
6 B- Encoder phase B- input
7 GND 0 V
8 BK+ Brake release + side
9 NC Not connected
10 NC Not connected
11 HS_U Hall sensor phase U
12 A+ Encoder phase A+ input
13 HS_W Hall sensor phase W
14 BK- Brake release - side
15 NC Not connected
16 HS_V Hall sensor phase V
17 A- Encoder phase A- input
18 VPS Encoder line driver enable output
19 NC Not connected
20 LS+ Limit switch + side
21 VCC Encoder power 5V
22 NC Not connected
23 NC Not connected
24 FG Frame ground
