5.4 Part Names/Functions and External Dimensions
A5-20
ME0384-4A
Chapter 5 200V Driver Unit 200V Power Supply Unit
[Terminal Unit for 200V]
Danger
● When 200V units are to be connected, make sure to use the terminal unit for 200V
(RCON-GW-TRS) enclosed in the 200V power supply unit.
The terminal unit for 24V has a structure that does not allow itself connected to the
200V driver unit, however, it could be forcefully inserted, which could cause fire on the
connector as well as damage on it.
RCON-GW-TRS
Left side Right side Rear
Bottom Parts for Terminal Unit
Upper Parts for Terminal Unit
Connector
To Next Page
