Chapter 1 Overview
1.1 Checking the Product
Prepare the following devices.
Caution
● The RCON system does not link each unit; individual units are packaged and shipped.
● When unpacking, make sure first that each unit you ordered is present in the correct
quantity.
● Below are examples of the products shipped together.
[RCON Gateway Unit]
Part name Shape Quantity Remarks
RCON gateway
unit
1
Model example:
RCON-GW/GWG
Field network
cable connector
1
(
Enclosed
in
connection
types
described
on the
right)
Model:
MSTB2.5/5-STF-5.08 AU
* Enclosed to RCON
gateway unit CC-Link
connection Type
Model:
MSTB2.5/5-STF-5.08 AU M
* Enclosed to RCON
gateway unit DeviceNet
connection type
Fan unit
(Option)
Depends
on
gateway
unit model
Model: RCON-FU
* Supplied with RCON
gateway unit
System I/O connector 1
Model: DFMC1.5/5-ST-3.5
* Supplied with RCON
gateway unit
Terminal unit 1
Model: RCON-GW-TR
* Supplied with RCON
gateway unit
