1.1 Checking the Product
B1-3
ME0384-4A
Startup Section
Chapter 1 Overview
[200V Power Supply Unit]
Part name Shape Quantity Remarks
200V Power Supply Unit 1 Model: RCON-PS2-3
Terminal Unit for 200V
1
Depends on
model type of
power supply
unit
Single product model
number: RCON-GW-TRS
(Not enclosed to TRN type)
Fan unit
1
(per unit)
Single product model
number: RCON-FU
* Enclosed to 200V power
supply unit
Power connector
1
(per unit)
Single product model
number: SPC5/4-STF-7.62
(Phoenix Contact)
* Enclosed to 200V power
supply unit
[EC Connection Unit]
Part name Shape Quantity Remarks
EC Connection Unit 1
Model example:
RCON-EC
Drive source shutoff
connector
1
(per unit)
Model:
DFMC1.5/4-ST-3.5
(Phoenix Contact)
* Enclosed to EC
connection unit
