1.2 Tools to Use
B1-5
ME0384-4A
1.2 Tools to Use
The tools used for constructing and starting up the RCON system are PC software or a teaching
pendant, and the gateway parameter configuration tool.
The applicable versions are as shown below. The versions in brackets are the applicable
versions when using the 200V driver unit or EC connection unit.
[PC software]
● RCM-101-*-* Ver.13.00.00.00 or later (Ver. 13.01.00.00 or later)
[Teaching pendant]
● TB-02/TB-02D Ver.2.10 or later (Ver.2.70 or later)
● TB-03 Ver.2.10 or later (Ver.2.70 or later)
[Gateway parameter configuration tool]
● Ver.3.1.0.0 or later (Ver.3.1.7.0 or later)
The gateway parameter configuration tool is included in the PC software, but you can also
download the latest version from our website.
For the operation of PC software and teaching pendant, refer to the following instruction manual.
Reference
PC software operating method PC software (RCM-101-*-*) manual (ME0155)
Teaching pendant operating method Touch Panel Teaching Pendant manual
TB-02/02D (ME0355), TB-03 (ME0376)
To Next Page
