5.1 Operation Confirmation with PC Software
B5-11
ME0384-4A
Perform home return for the actuator.
(1) Click .
(2) When the actuator starts home return motion and the home return completes normally
changes to . (The lamp lights up in green.)
Caution
● The home return speed cannot be changed. Increasing this speed may increase the
impact when the actuator operating part hits the mechanical end, which may adversely
affect the actuator mechanism in the long run or increase the error of the home
position.
"Edit position data" screen
(1) Click
To Next Page
