6.1 Parameter
B6-14
ME0384-4A
[Home Sensor Polarity (Parameter No. 18)]
No. Name Unit Input range
Default initial value setting
18 Home sensor polarity － 0 to 2 In accordance with actuator
A parameter to select input polarity of the home sensor.
Home sensor is optional.
Set value Content
0
Standard specification
(home sensor not in use)
1 Input is a-contact
2 Input is b-contact
[Overrun sensor input polarity (Parameter No. 19)]
No. Name Unit Input range
Default initial value setting
19
Overrun sensor input
polarity
－ 0 to 2 In accordance with actuator
This parameter is set properly prior to the shipment according to the specification of the
actuator.
Set value Content
0 Standard specification without sensor
1 Over travel detection sensor input is a contact
2 Over travel detection sensor input is b contact
AC
servo motor specification and
stepper motor specification only
200V AC servo motor specification only
