6.1 Parameter
B6-23
ME0384-4A
[Home Confirmation Sensor Input Polarity (Parameter No. 43)]
No. Name Unit Input range
Default initial value setting
43
Home confirmation
sensor input polarity
－
0: Sensor not in use
1: a-contact
2: b-contact
In accordance with actuator
Sets input signal polarity of the home confirmation sensor (optional).
The home confirmation sensor is mounted on the mechanical end. If inverted before reaching
the mechanical end due to interference, etc. it will be recognized as a positioning diversion and
alarm code 0BA "Home Sensor Undetected" will be output.
There is normally no need to make changes.
Set value Content
0
Home confirmation sensor not in use
1 Sensor polarity is a-contact
2 Sensor polarity is b-contact
[Velocity Override (Parameter No. 46)]
No. Name Unit Input range
Default initial value setting
46 Velocity override % 1 to 100 100
When executing travel commands from the PLC side, override can be applied against the travel
speed set in the "Speed" field in the position table. Minimum setting unit is 1%, and input range
is 1 to 100%.
Invalid against travel commands from a teaching tool such as PC software.
Actual travel speed = [speed set in position table] x [set value of Parameter No. 46]
Example) If the value in the "Speed" column of the position table is 500 mm/s and parameter
No. 46 is 20%, the actual travel speed will be 100 mm/s.
24V AC
servo motor specification
and stepper motor specification only
