16
MENU SCREEN
16-41
■ GPS items (Continued)
GPS Logger (Default: ON)
GPS > GPS Logger > GPS Logger
Turn the GPS Logger function ON or OFF.
This function logs the position, altitude, course, speed and number of satel-
lites being used.
• OFF: Turns the function OFF.
• ON: The transceiver automatically logs GPS data.
Once this function is turned ON, the GPS data will be continuously
logged until turning it OFF, even if the transceiver power is turned
OFF, then ON again.
To use this function:
1. You must first insert a microSD card into the transceiver.
2. You must select either Internal GPS or External GPS in GPS select.
NOTE:
The log data will be saved on the microSD card.
The file name is automatically created, as shown in the example below:
Log start date and time: 2016/10/1 15:30:00
File name: 20161001_153000.log
You can select the GPS record sentence for the GPS Logger function.
Record Interval (Default: 5sec)
GPS > GPS Logger > Record Interval
Select the GPS Logger function record interval of 1, 5, 10, 30 or 60 seconds.
Record Sentence (Default:
□✔RMC/□✔GGA/□✔GLL/□✔VTG
)
GPS > GPS Logger > Record Sentence
Set the GPS Logger function record sentence to RMC, GGA, GLL, or VTG.
NOTE: Select at least one sentence, otherwise an error beep will sound.
To Next Page
