3-48 INSPECTIONS / GENERAL INSPECTION TASKS
ICON A5 / MAINTENANCE MANUAL CHANGE C2
1. Guide the forward “tongue” of the forward floor board through the gap under the heel strike
fitting.
2. Slide he tabs in the floor’s forward edge into the receiving slots in the forward floor support.
3. Place the aft floor board into position, align the four ball socket fasteners and press down until
the balls engage the sockets.
VERIFICATION METHOD:
Task is complete when the cockpit floor board is installed.
RELATED INFORMATION:
"Seat Pan Installation" on page 3-53
"Rigging Roll Controls" on page 9-20
"Inspect Roll Cable Tension" on page 9-13
"Rigging Yaw Controls" on page 9-87
"Rigging Pitch Controls" on page 9-46
3.6.2.11 Cockpit Sidewall Panel Removal
Use the following procedure to install the cockpit sidewall panel.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
NA
Consumables
None
