3-28 INSPECTIONS / WEIGHT AND BALANCE—GENERAL
ICON A5 / MAINTENANCE MANUAL CHANGE C2
Maximum Baggage/Cargo Weight
60 lb
f
WARNING: Loading a concentrated weight fully aft in the baggage area may
cause an unsafe CG condition.
Cargo Restraints
Are rated to hold 1,000 lb
f
Minimum Number of Anchor Loops
At least three (3) out of six (6) provided anchor loops must be used in order to safely restrain the
full baggage/cargo load.
Minimum Load Rating of Cargo Restraints (Pilot Supplied)
1,000 lb
f
Full Usable Fuel Weight
120 lb
f
(20 US gal at 6 lb
f
per US gal)
Removable Side Window Weight and Fuselage Station
7.18 lb
f
(total both windows)
FS 127.6
Removable Wind Deflector Weight and Fuselage Station
0.3 lb
f
(total both deflectors)
FS 113.4
3.4.3 CG Limits and Station Information
Maximum Takeoff Weight (MTOW)
1,510 lb
f
Reference Datum
FS 154.75 (located on forward face of wing spar carry-through)
Forward CG Limit
FS 153.0
Aft CG Limit
FS 159.2
NOTE: See the Weight and CG Envelope Limits figure for further details on
the acceptable operating envelope.
