10-30 FUEL SYSTEM / FINE FUEL FILTER
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 10
10.7 Fine Fuel Filter
RELATED INFORMATION:
"Headliner Removal" on page 3-37
"Headliner Installation" on page 3-38
10.7.1 Maintenance Instructions
10.7.1.1 Remove Fine Fuel Filter
Use the following instruction to remove the fine fuel filter.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
07—Fuel System
Consumables
None
TASK INSTRUCTIONS:
1. Remove headliner. (See “Headliner Removal” on page 3-37.)
2. Close the fuel shutoff valve.
3. Have a rag or container available to contain any fuel that leaks from the fuel lines and filter.
4. Use a 13/16 wrench to hold the union fitting at the fuel pressure relief block while loosening the
adjacent -6 AN B-nut with an 11/16 wrench shown in Figure 10-12. Catch the fuel as it leaks from
the joint.
