11-8 FUSELAGE AND VERTICAL TAIL / SEAWINGS™
ICON A5 / MAINTENANCE MANUAL CHANGE C1
5. With tip in hand, line up the four pins and slide the tip into place with a firm forward and inward
push.
6. Install the AN3-C5A retaining bolt with two NAS1149C0363R washers inside the wheel well.
Torque to 26 in-lb
f
VERIFICATION METHOD:
Firmly grasp the Seawings™ tip and, tugging up/down and fore/aft, verify that it is securely attached
and that there are no large open gaps between it and the Seawings™.
RELATED INFORMATION:
"Description" on page 20-2
"Repair of Seawings™ Tip Attach Pins and Bushings" on page 11-8
11.3.1.2 Repair of Seawings™ Tip Attach Pins and Bushings
Use the following procedure to repair the Seawings™ tip attach pins and bushings.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
ICA010317 Bushing (NAS77C3-012 is obsolete for new installations)
SS-M4-RB23-4 Pin
Aircraft System and Number
08—Fuselage and Vertical Tail
Consumables
Isopropyl Alcohol
Plexus MA830 Adhesive
1. Remove the Seawings™ tip using the removal procedure. (See “Seawings™ Platform Tip
Removal and Installation” on page 11-7.)
