ICON A5 - Left Instrument Panel Top Panel Installation

EQUIPMENT AND FURNISHINGS / EQUIPMENT AND FURNISHINGS GENERAL MAINTENANCE 8-21
CHANGE C1 ICON A5 / MAINTENANCE MANUAL
CHAPTER 8
RELATED INFORMATION:
"Replace Instrument Panel Gauge" on page 13-26
"Heater Fan and Core Removal" on page 7-3
"Canopy Removal" on page 11-3
"Canopy Installation" on page 11-4
"Nose Landing Gear (NLG) Leg Assembly Removal" on page 14-60
"Remove Landing and Taxi Lights" on page 6-58
8.2.11 Left Instrument Panel Top Panel Installation
Use the following procedure to install the left instrument panel top panel.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
None
Aircraft System and Number
05—Equipment and Furnishing
Consumables
LOCTITE
®
243™
TASK INSTRUCTIONS:
1. Install left instrument panel top first by locating it in position carefully around the instrument
cluster, then:
a. Install air vent hose and clamp.
b. Install 6-32 screw with washer under its head behind right eyeball air valve, torquing to 9
in-lb
f
.
c. Install 8-32 screws at left-forward side of and aft-right corner of panel, torquing each to 13
in-lb
f
.
2. Install right eyeball air valve using special tool ITL001563, aligning tooling holes to 6 and 12
o’clock positions.
3. Install Throttle Handle and Bezel. (See “Throttle Handle and Bezel Installation” on page 8-13.)
