13-26 INSTRUMENTS (AND AVIONICS) / INSTRUMENTS AND AVIONICS GENERAL MAINTENANCE
ICON A5 / MAINTENANCE MANUAL CHANGE C2
4. The light goes solid GREEN at the end of the calibration mode. If there are any errors the light is
left in a solid RED illuminated state.
5. Turn off the master switch.
RESULT:
Increased accuracy and the ability to adjust for sensor aging and varying environmental conditions to
obtain the most accurate result possible.
VERIFICATION METHOD:
Inspect the indicator LED to ensure that it is solid GREEN color.
RELATED INFORMATION:
"Condition and 100-Hour Inspection—Avionics and Electrical" on page 3-23
13.3.4 Replace Instrument Panel Gauge
Use the following to replace any of the nine gauges in the flight instrument panel.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
None
Parts Required
ICA010987 (INDICATOR, ANGLE OF ATTACK, 2.25DIA)
ICA013217 (INDICATOR, AIRSPEED, 3.12DIA)
ICA011296 (INDICATOR, ATTITUDE)
ICA010989 (INDICATOR, ALTIMETER, SINGLE PTR, 3.12DIA)
ICA010990 (INDICATOR, FUEL QTY, 2.25 DIA)
ICA010992 (INDICATOR, OIL TEMP, 1.25 DIA)
ICA010993 (INDICATOR, OIL PRESSURE, 1.25 DIA)
ICA010994 (INDICATOR, COOLANT TEMP, 1.25 DIA)
ICA010991 (INDICATOR, TACHOMETER, 2.25 DIA)
