10-8 FUEL SYSTEM / FUEL SYSTEM GENERAL MAINTENANCE
ICON A5 / MAINTENANCE MANUAL CHANGE C2
CHAPTER 10
10.3.2 Pump Usable Fuel From Fuel Tank
Use this procedure when it is necessary to pump the usable fuel from the fuel tank.
TASK INFORMATION:
Type of Maintenance
Line
Level of Certification
LSA-RM
Task Specific Training Required
No
Special Tools Required
A suitable length of -6 AN fuel hose with a -6 male AN flare fitting at one end.
Parts Required
None
Aircraft System and Number
07—Fuel System
Consumables
None
CAUTION: Do not perform any work on the aircraft fuel system unless the
aircraft is grounded to a suitable ground to earth.
TASK INSTRUCTIONS:
1. Attach a grounding cable to the bow ring.
2. Remove the top engine cowl. (See “Remove Engine Cowlings” on page 16-13.)
3. Use an 11/16 wrench to disconnect the fuel supply hose at the fuel rail on the engine’s
left-forward corner (circled in Figure 10-1). Catch any fuel that drips out.
